TM Serie

Sloped roof for CP & MC series

Standard Specifications

In Stainless steel AISI 304 (EN 1.4301), Scotch-Brite finishing
Suitable for outdoor installations
Grant the protection against weathering
Prepared for being fixed on the cabinet in corrispondance of the eye bolts

On Request

In Stainless steel AISI 316 (EN 1.4404), Scotch-Brite finishing.

Request Documentation and Quotations

Product Drawing

Technical Data

Model	Roof top size (mm)		Cabinet size (mm)		Anti-insect netting
Code	L	P	L	P	Code
TM64	700	700	600	400	GA 60
TM65	700	800	600	500
TM66	700	900	600	600
TM84	900	700	800	400	GA 80
TM85	900	800	800	500
TM86	900	900	800	600
TM104	1100	700	1000	400	GA 100
TM105	1100	800	1000	500
TM106	1100	900	1000	600
TM124	1300	700	1200	400	GA 120
TM125	1300	800	1200	500
TM126	1300	900	1200	600
TM164	1700	700	1600	400	GA 160
TM165	1700	800	1600	500
TM166	1700	900	1600	600
