BG Series

Technical Data

Drawing

Certifications

Accessories

Standard Specifications

  • In Stainless steel AISI 304 (EN 1.4301), Scotch- Brite finishing
  • Tubes with a diameter of both 48 and 60mm
  • Available in 4 differents shapes: I, J, L, S
  • Prepared to be welded to our swivel and fixed joints

On Request Heading

  • In Aisi 316 stainless steel (EN 1.4404) Scotch-Brite finish
  • Customizations to design
Request Documentation and Quotations

Product Drawing

×

Technical Data

ModelDiameter (mm)Dimensions (mm)
CodeModelØMinimum LMinimum H / H1
BG48IIØ 48 300
BG48JJØ 48450245
BG48LLØ 48245245
BG48SSØ 48245750
BG60IIØ 60 300
BG60JJØ 60450245
BG60LLØ 60245245
BG60SSØ 60245750
