EQP Serie

Commander

In Stainless steel AISI 304 (EN 1.4301), 1.2 – 1.5mm thick (depending on the dimensions), Scotch-Brite finishing.
Rear blind door, 1.2 – 1.5mm thick (depending on the dimensions), Scotch-Brite finishing.
Stainless steel internal hinges, allowing the opening up to 135°.
Bi-component polyurethane foam gasket
Stainless steel handles in AISI 304 (EN 1.4301)
Top or bottom reinforced for fixing a fix or a swivel arm or a pedestal

Request Documentation and Quotations

Model	Dimensions (mm)			Mounting plate (optional)	Dimensions of the mounting plate (mm)		Handles
Code	L	H	P	Code	L	H	Code	H1 mm
EQP 353015	350	300	150	PEP3030	295	245	HS 1220	200
EQP 403015	400	300	150	PEP4030	345	245	HS 1220	200
EQP 403515	400	350	150	PEP4035	345	295	HS 1225	250
EQP 404015	400	400	150	PEP4040	345	345	HS 1230	300
EQP 454015	450	400	150	PEP4540	395	345	HS 1230	300
EQP 504015	500	400	150	PEP5040	445	345	HS 1235	350
EQP 554515	550	450	150	PEP5545	495	395	HS 1235	350
EQP 555015	550	500	150	PEP5550	495	445	HS 1235	350
