Drawing
Certifications
Accessories
| H100 | ||||
|---|---|---|---|---|
| Model | Dimensions (mm) | Side panel | ||
| Code | L | H | P | Code |
| CS614 | 600 | 100 | 400 | LP 41 |
| CS615 | 600 | 100 | 500 | LP 51 |
| CS616 | 600 | 100 | 600 | LP 61 |
| CS814 | 800 | 100 | 400 | LP 41 |
| CS815 | 800 | 100 | 500 | LP 51 |
| CS816 | 800 | 100 | 600 | LP 61 |
| CS1014 | 1000 | 100 | 400 | LP 41 |
| CS1015 | 1000 | 100 | 500 | LP 51 |
| CS1016 | 1000 | 100 | 600 | LP 61 |
| CS1214 | 1200 | 100 | 400 | LP 41 |
| CS1215 | 1200 | 100 | 500 | LP 51 |
| CS1216 | 1200 | 100 | 600 | LP 61 |
| CS1614 | 1600 | 100 | 400 | LP 41 |
| CS1615 | 1600 | 100 | 500 | LP 51 |
| CS 1616 | 1600 | 100 | 600 | LP 61 |
| H200 | ||||
|---|---|---|---|---|
| Model | Dimensions (mm) | Side panel | ||
| Code | L | H | P | Code |
| CS624 | 600 | 200 | 400 | LP 42 |
| CS625 | 600 | 200 | 500 | LP 52 |
| CS626 | 600 | 200 | 600 | LP 62 |
| CS824 | 800 | 200 | 400 | LP 42 |
| CS825 | 800 | 200 | 500 | LP 52 |
| CS826 | 800 | 200 | 600 | LP 62 |
| CS1024 | 1000 | 200 | 400 | LP 42 |
| CS1025 | 1000 | 200 | 500 | LP 52 |
| CS1026 | 1000 | 200 | 600 | LP 62 |
| CS1224 | 1200 | 200 | 400 | LP 42 |
| CS1225 | 1200 | 200 | 500 | LP 52 |
| CS1226 | 1200 | 200 | 600 | LP 62 |
| CS1624 | 1600 | 200 | 400 | LP 42 |
| CS1625 | 1600 | 200 | 500 | LP 52 |
| CS1626 | 1600 | 200 | 600 | LP 62 |
