WP Serie

Window cover

In Stainless steel AISI 304 (EN 1.4301), Scotch-Brite finishing.
Lexan door, with stailess steel frame 1.2 – 1.5mm thick (depending on the dimensions), Scotch-Brite finishing.
External hinges, allowing the opening up to 90°
EPDM gasket
Stainless steel locking systems or polyamide butterfly lock

Request Documentation and Quotations

Version with double bit insert lock	Version with locking wing knob	Window size (mm)			Lexan clearance (mm)
Code	Code	L	H	P	L	H
WP 33 B	WP 33 F	300	300	40	190	205
WP 44 B	WP 44 F	450	450	40	340	355
WP 46 B	WP 46 F	450	600	40	340	505
WP 55 B	WP 55 F	500	500	40	390	405
WP 57 B	WP 57 F	500	700	40	390	605
WP 66 B	WP 66 F	600	600	40	490	505
WP 75 B	WP 75 F	700	500	40	590	405
WP 77 B	WP 77 F	700	700	40	590	605
WP 88 B	WP 88 F	800	800	40	690	705
