HCS Serie

Hygienic Design Modular Cabinet

Door with external hinges EHEDG certified
30° sloping roof
In Stainless steel AISI 304 (EN 1.4301), Scotch-Brite finishing.
Solid door, 2mm thick, with its perimeter edge inclinated of 10°
External hinges patented and EHEDG Certified
180° door opening and maximum load up to 100Kg
EHEDG certified locking system.
Silicon blue gasket following the FDA requirements.
30° sloping roof
Internal mounting plate in galvanized steel, 2.5 mm thick, with frontal insertion
3A certified

Request Documentation and Quotations

HC	Dimensions (mm)				Door	Hygienic Locks & Hinges	Mounting Plate Dimensions (mm)		Useful drilling space (mm)
Code	L	H	H1	W	Nr.	Nr.	L2	H2	L3	H3
HCS 6016040	600	1600	1880	400	1	4	485	1520	500	1530
HCS 6016050	600	1600	1938	500	1	4	485	1520	500	1530
HCS 8016040	800	1600	1880	400	1	4	685	1520	700	1530
HCS 8016050	800	1600	1938	500	1	4	685	1520	700	1530
HCS 10016040	1000	1600	1880	400	1	4	885	1520	900	1530
HCS 6018040	600	1800	2080	400	1	4	485	1720	500	1730
HCS 6018050	600	1800	2138	500	1	4	485	1720	500	1730
HCS 8018040	800	1800	2080	400	1	4	685	1720	700	1730
HCS 8018050	800	1800	2138	500	1	4	685	1720	700	1730
HCS 10018040	1000	1800	2080	400	1	4	885	1720	900	1730
HCS 6020040	600	2000	2280	400	1	4	485	1920	500	1930
HCS 6020050	600	2000	2338	500	1	4	485	1920	500	1930
HCS 8020040	800	2000	2280	400	1	4	685	1920	700	1930
HCS 8020050	800	2000	2338	500	1	4	685	1920	700	1930
HCS 10020040	1000	2000	2280	400	1	4	885	1920	900	1930
