HES Serie

Technical Data

Drawing

Certifications

Accessories

Standard Specification

  • Door with external hinges EHEDG certified
  • 30° sloping roof covering the door
  • In Stainless steel AISI 304 (EN 1.4301), Scotch-Brite finishing.
  • Solid door, 2mm thick with its perimeter edge inclinated of 10°
  • Opening of the door upwards with gas piston
  • External hinges patented and EHEDG Certified.
  • Maximum load of the door 70 kg.
  • EHEDG certified locking system.
  • Silicon blue gasket following the FDA requirements.
  • 30°sloping roof covering the door.
  • Internal mounting plate in galvanized steel,2.5 mm thick
  • 3A certified

On Request Heading

  • Door with EHEDG-certified external hinges
  • 30° sloping roof covering the door
  • Made of AISI 304 (EN 1.4301) stainless steel with a Scotch-Brite finish
  • 2mm thick solid door with a 10° sloping edge
  • Upward opening door with gas springs
  • Patented and EHEDG-certified external hinges
  • Door capacity up to 70 kg
  • EHEDG-certified hygienic locking mechanism
  • Blue silicone seal compliant with FDA guidelines
  • 30° sloping roof covering the door
  • 2.5 mm thick Fe/Zn base plate
  • 3A certified
Request Documentation and Quotations

Standard Certifications

Product Drawing

×

Technical Data

Art.
Dimensions (mm)
Door
Mounting Plate Dimensions (mm)
Hygienic Locks & Hinges
Back Inserts M6
Distance rear inserts M6 (mm)
Useful Drilling Space (mm)
CodeLHH1WNr.L2H2Nr.Nr.L3H3L4H4
HES 454525450450573250135544524330430350380
HES 455025450500623250135549524330480350430
HES 456025450600723250135559524330580350530
HES 505025500500623250140549524330480350430
HES 507025500700823250140569524380680400630
HES 606025600600723250150559524480580500530
HES 607530600750901300150574524480730500680
HES 608030600800951300150579524480780500730
HES 601003060010001151300150599526480980500930
