HE-MG Serie

Technical Data

Drawing

Certifications

Accessories

Standard Specification

  • Door with external hinges EHEDG certified
  • 30° sloping roof
  • In Stainless steel AISI 304 (EN 1.4301), Scotch-Brite finishing.
  • Solid door, 2mm thick, with its perimeter edge inclinated of 10°
  • External hinges patented and EHEDG Certified.
  • 180° door opening and maximum load up to 45Kg
  • EHEDG certified locking system.
  • Silicon blue gasket following the FDA requirements.
  • 30°sloping roof.
  • Internal mounting plate in galvanized steel, 2,5mm thick
  • 3A certified

On Request Heading

  • Acciaio Inox Aisi 316L (EN 1.4404)
  • Boccole M6 cieche sul retro
  • Design customization
Request Documentation and Quotations

Standard Certification

Product Drawing

×

Technical Data

Art.
Dimensions (mm)
Door
Mounting Plate Dimensions (mm)
Hygienic Locks & Hinges
Back Inserts M6
Distance rear inserts M6 (mm)
Useful Drilling Space (mm)
CodeLHH1WNr.L2H2Nr.Nr.L3H3L4H4
HE 804525 MG800450642250170544524680430700350
HE 904525 MG900450642250180544524780430800350
HE 1004525 MG1000450642250190544526880430900350
HE 806030 MG800600821300170559524680580700500
HE 1006030 MG1000600821300190559526880580900500
HE 1206030 MG1200600821300111055952610805801100500
HE 1007040 MG1000700978400190569526880680900600
HE 1207040 MG1200700978400111056952610806801100600
HE 1407040 MG1400700978400113056952612806801300600
