HSF Series

Push Buttons

Coat and lid made of Stainless Steel Aisi 304 (EN 1.4301) Scotch-Brite finish
Perforated lid as shown in the table 2mm thick, fixed with Hygienic Design captive screws
Blue silicone gasket complying with FDA guidelines
Blind M5 bushings on the back

Request Documentation and Quotations

Model	Dimensions (mm)			Holes Ø 22,5mm	Mounting Plate (optional)	Dimensions (mm)		Back Inserts M5	Distance (mm)		Useful Drilling Space (mm)
Code	L	H	W	Nr.	Code	L	H	Nr.	L1	H1	L2	H2
HSF 1010	100	100	90	1	/	/	/	2		70	50	50
HSF 1016	100	160		2	/	/	/	2		130	50	110
HSF 1020	100	200		3	/	/	/	2		170	50	150
HSF 1028	100	280		4	/	/	/	2		250	50	230
HSF 1616	160	160	110	2x2	PSJ1616	123	123	4	110	110	110	110
HSF 1625	160	250		4x2	PSJ1625	123	213	4	110	200	110	200
HSF 2020	200	200		3x2	PSJ2020	163	163	4	150	150	150	150
HSF 2025	200	250	130	3x4	PSJ2520	163	213	4	150	200	150	200
HSF 2525	250	250		4x4	PSJ2525	213	213	4	200	200	200	200
HSF 2030	200	300		3x5	PSJ2030	163	263	4	150	250	150	250
HSF 3030	300	300	150	5x5	PSJ3030	263	263	4	250	250	250	250
