CPO Series

Horizontal case with removable sides

In Stainless steel AISI 304 (EN 1.4301), Scotch- Brite finishing
Mantle thickness 1.5mm
Screwed side walls, 1.2-1.5mm thick depending on size
Hinged blind door with inside shoulder rotation, opening 110°, thickness 1.2-1.5mm depending on size
Cast stainless steel hinges
Two-component polyurethane foam gasket
FeZn inner plate 2.5mm thick with front insertion

Request Documentation and Quotations

	Model	Dimensions (mm)	Removable sides	Dimensions of the mounting plate (mm)	Number of rear M6 nuts	Distance between rear nuts (mm)
	Code	L	H	P	Code	L	H		L1	H1
Two doors	CPO 1206040	1200	600	400	WPF 64	1145	555	6	565	530
	CPO 1208040	1200	800	400	WPF 84	1145	755	6	565	730
	CPO 1206050	1200	600	500	WPF 65	1145	555	6	565	530
	CPO 1208050	1200	800	500	WPF 85	1145	755	6	565	730
	CPO 1606040	1600	600	400	WPF 64	1545	555	6	765	530
	CPO 1608040	1600	800	400	WPF 84	1545	755	6	765	730
	CPO 1606050	1600	600	500	WPF 65	1545	555	6	765	530
	CPO 1608050	1600	800	500	WPF 85	1545	745	6	765	730
