EQM Series

Case with lexan door and counter door for modular equipment

“In Stainless Steel Aisi 304 (EN 1.4301) Scotch-Brite finish.
Coat thickness 1.2-1.5mm depending on size
Reversible transparent lexan hinged door with 135° opening, stainless steel thickness 1.2-1.5mm depending on size
Cast stainless steel hinges
Two-component polyurethane foam gasket
Perforated panel kit for housing modular switches, screwed and complete with depth-adjustable brackets for DIN rail support
M6 blind bushings on the back
FeZn inner plate sp.2.5mm”

Request Documentation and Quotations

Model	Dimensions (mm)	Modules	Number of modular panels	Code of the mounting plate	Dimensions of the mounting plate (mm)	Number of rear M6 nuts	Distance between rear M6 nuts (mm)
Code	L	H	P		H100		L	H		L1	H1
EQM 405020	400	500	200	32	2+1	PE4050	355	445	4	330	430
EQM 454520	450	450	200	36	2	PE4545	405	395	4	380	380
EQM 456025	450	600	250	36	2+1	PE4560	405	545	4	380	530
EQM 507025	500	700	250	60	3+1	PE5070	455	645	4	430	630
EQM 606025	600	600	250	48	2+1	PE6060	555	545	4	530	530
EQM 607530	600	750	300	72	3+1	PE6075	555	695	4	530	680
EQM 609030	600	900	300	96	4+1	PE6090	555	845	4	530	830
EQM 7510030	750	1000	300	180	5+1	PE75100	705	945	6	680	465
EQM 8012030	800	1200	300	228	6+1	PE80120	755	1145	6	730	565
