MCR Serie

Intermediate or terminal cable ascent

Standard Specifications

In Stainless steel AISI 304 (EN 1.4301), Scotch-Brite finishing.
Blind door, 1.5mm thickness, Scotch-Brite finishing.
Stainless steel internal hinges, allowing the opening up to 110°.
Door complete with pre-drilled internal frame in galvanized steel
Removable rear panel and cover

On Request Heading

In Stainless steel AISI 316 (EN 1.4404), Scotch-Brite finishing.
Depth adjustable internal mounting plate in galvanized steel, 2.5 mm thick.
Design according to customer’s drawing

Request Documentation and Quotations

Standard Certifications

On Request

Technical Data

MCR	Model	Cabinet size (mm)			Mounting plate (mm)			Plinth base		Side panels	Drilling area on the door (mm)
	Code	L	H	P	Code	L	H	H100 Code	H200 Code	Code	L1	H1
Single door	MCR 3184	300	1800	400	PS 318	185	1720	ZM 31	ZM 32	WL 41	125	1655
	MCR 3185	300	1800	500	PS 318	185	1720	ZM 31	ZM 32	WL 51	125	1655
	MCR 3186	300	1800	600	PS 318	185	1720	ZM 31	ZM 32	WL 61	125	1655
	MCR 4184	400	1800	400	PS 418	285	1720	ZM 41	ZM 42	WL 41	225	1655
	MCR 4185	400	1800	500	PS 418	285	1720	ZM 41	ZM 42	WL 51	225	1655
	MCR 4186	400	1800	600	PS 418	285	1720	ZM 41	ZM 42	WL 61	225	1655
	MCR 3204	300	2000	400	PS 320	185	1920	ZM 31	ZM 32	WL 42	125	1855
	MCR 3205	300	2000	500	PS 320	185	1920	ZM 31	ZM 32	WL 52	125	1855
	MCR 3206	300	2000	600	PS 320	185	1920	ZM 31	ZM 32	WL 62	125	1855
	MCR 4204	400	2000	400	PS 420	285	1920	ZM 41	ZM 42	WL 42	225	1855
	MCR 4205	400	2000	500	PS 420	285	1920	ZM 41	ZM 42	WL 52	225	1855
	MCR 4206	400	2000	600	PS 420	285	1920	ZM 41	ZM 42	WL 62	225	1855
